Planar 10
A reference-level belt-drive turntable with a skeletal Tancast 8 plinth, ceramic bracing, a factory-fitted RB3000 tonearm and an outboard PL10 power supply. It is aimed at listeners building a high-end vinyl system around a lightweight, rigid design.
- Tancast 8 foam core skeletal plinth with HPL skin
- Ceramic top brace and phenolic resin bottom brace (DB technology)
- RB3000 tonearm with preloaded zero-tolerance bearing
- Diamond-cut ceramic oxide platter
- 24 V synchronous motor with outboard PL10 PSU and electronic speed change
- Matt Polaris grey or matt white finish; lifetime limited warranty
Fotografii
8Anunțuri
Încă nu sunt anunțuri pentru acest model
Când cineva vinde un Planar 10, anunțurile și istoricul vânzărilor vor apărea aici.
Vinde unul la felDescriere
The Planar 10 is built around a skeletal plinth made from a Tancast 8 polyurethane foam core between two layers of high-pressure laminate. A ceramic top brace and a phenolic resin bottom brace sit between the tonearm mount and the main bearing. The plinth is described as 30% lighter than the original RP10 while being stiffer.
The platter is a ceramic oxide flywheel that is fired and diamond cut for flatness. It turns on a low-mass hub bearing with a one-piece machined aluminium sub-platter and a hardened tool steel spindle in a brass housing. A 24 V synchronous motor, mounted from underneath, drives the platter through an EBLT belt. Each motor is hand-tuned to its own PL10 PSU, which provides electronic speed change and fine speed adjustment.
The RB3000 tonearm has a preloaded bearing assembly and an aluminium arm tube, and uses no adhesive in its construction. An Apheta 3 or Aphelion 2 cartridge can be factory fitted as an option. It comes with a removable single-piece dust cover and in two matt finishes.
Video
Specificații
- Marcă
- Rega
- Model
- Planar 10
- Categorie
- Hi-Fi și audio pentru casă › Pickupuri
Turntable
- Drive type
- Belt drive (EBLT reference belt)
- Plinth
- Tancast 8 foam core with HPL skin
- Bracing
- Ceramic top brace, phenolic resin bottom brace
- Platter
- Ceramic oxide, diamond cut
- Main bearing
- Machined aluminium sub-platter, hardened tool steel spindle, brass housing
- Dust cover
- Removable single-piece
Tonearm and cartridge
- Tonearm
- RB3000
- Arm tube
- Hand-polished aluminium
- Factory-fitted cartridge options
- Apheta 3 or Aphelion 2 (optional)
Motor and power
- Motor
- 24 V synchronous, low vibration
- Power supply
- PL10 PSU (P10 PSU), outboard
- Speed control
- DSP generator on a crystal reference, electronic speed change
- Fine speed adjustment
- User adjustable, electronic
Physical
- Turntable dimensions (W x H x D)
- 420 x 115 x 350 mm (with dust cover fitted)
- Turntable weight
- 4.7 kg
- PSU dimensions (W x H x D)
- 218 x 80 x 320 mm
- PSU weight
- 3 kg
- Finishes
- Matt Polaris grey, matt white
Warranty
- Warranty
- Lifetime limited warranty against manufacturing defects
