EW IEM G4
Wireless in-ear monitoring set for stage use, combining a half-rack stereo transmitter with a bodypack receiver and IE 4 earphones. It suits performers who need a personal monitor mix with tunable UHF frequencies.
- Half-rack stereo transmitter with full-metal housing and OLED display
- Bodypack receiver with IE 4 earphones included
- Up to 42 MHz bandwidth, 1680 selectable UHF frequencies
- Up to 16 compatible channels
- Range up to 100 m, RF output up to 50 mW
- Infrared sync between transmitter and receiver
Fotografii
5Anunțuri
Încă nu sunt anunțuri pentru acest model
Când cineva vinde un EW IEM G4, anunțurile și istoricul vânzărilor vor apărea aici.
Vinde unul la felDescriere
The EW IEM G4 is a complete in-ear monitoring package. A half-rack stereo transmitter in a full-metal housing sends the mix to a bodypack stereo receiver, and IE 4 earphones are supplied so the set can be used straight away. The transmitter has an OLED display for settings.
Transmission works in the UHF band with up to 42 MHz of bandwidth and 1680 selectable frequencies, with up to 16 compatible channels. RF output reaches up to 50 mW depending on country regulations, and range is stated as up to 100 metres. Transmitter and receiver are synchronised wirelessly by infrared, and frequencies can be managed with Sennheiser WSM software.
The transmitter takes audio through two XLR/6.3 mm jack combo sockets and has a 6.3 mm stereo jack output and a BNC antenna output. The receiver runs on two AA batteries for roughly 4 to 6 hours, depending on volume. A rackmount set and rod antenna are included.
Video
Specificații
- Marcă
- Sennheiser
- Model
- EW IEM G4
- Categorie
- Sonorizare live › Sisteme wireless
Inputs
- Audio input
- 2x XLR-3/¼" (6.3 mm) jack combo socket, electronically balanced
Outputs
- Audio output
- ¼" (6.3 mm) stereo jack socket, balanced
- Antenna output
- BNC socket, 50 Ω
Audio
- Audio frequency response
- 25 Hz to 15 kHz
- Signal-to-noise ratio
- >90 dB
- Total harmonic distortion (THD)
- <0.9 %
Wireless
- Receiver principle
- Adaptive diversity
- RF sensitivity
- < 4 μV, typ. 1.6 μV for 52 dBA rms S/N
- Squelch
- 5 to 25 dBµV, adjustable in steps of 2 dB
- Bandwidth
- Up to 42 MHz
- Selectable frequencies
- 1680
- Compatible channels
- Up to 16
- Transmission range
- Up to 100 meters / 300 feet
- RF output power
- Up to 50 mW, depending on country regulations
Power
- Battery operating time
- Approx. 4 to 6 hours (depending on volume level)
Physical
- Dimensions
- Approx. 202 x 212 x 43 mm
- Weight
- Approx. 980 g
In the box
- Included
- SR IEM G4 stereo transmitter, EK IEM G4 stereo receiver, IE 4 earphones, 2 AA batteries, rod antenna, rackmount set, power supply, quick guide, safety guide, manufacturer declaration sheet
